15PCS Mini Power Relay SRD-12VDC-SL-C 10A PCB Mount 5-Pin DC Power Relay for Universal Household Appliance（12V）
Product details
| Management number | 250053950 | Release Date | 2026/09/17 | List Price | US$2.92 | Model Number | 250053950 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Name: SRD-5V/12V/24VDC-SL-C Mini RelayRated Voltage: 5V / 12V / 24VMaximum Switching Current: 10AMaximum Switching Voltage: 250VACRated Coil Voltage: DCContact Release Time: 5msCoil Latching Type: Single Coil LatchingTermination Style: Plug-in Pins; Pin Count: 5Contact Form: Normally Open (NO)Coil Power: 0.36WMaximum Load Voltage: Low PowerMaximum Load Current: 10AOperating Temperature: -40 to +85℃Contact Material: Silver AlloyElectrical Life (Frequency: 1800 operations/hour): 100,000 cyclesMechanical Life (Frequency: 18000 operations/hour): 1,000,000 cyclesProduct Code Meaning:SRD - Model12VDC - Rated VoltageS - SealedL - Coil Power 0.36WC - Contact Form (5 Pins)
- The Relay Dimensions: 19.2mm (L) × 15.8mm (W) × 15.5mm (H) / 0.76in × 0.62in × 0.61in；Weight: Approximately 9g / 0.32oz;This relay is compact and suitable for PCB soldering.
- The relay features ultra-small size, standard PCB pin terminals, with a total of 5 pins.
- Load Options:10A 250VAC；10A 125VAC；10A 30VDC；10A 28VDC
- Coil Parameters:Pull-in Voltage (Maximum): 75% of Rated Voltage；Release Voltage (Minimum): 10% of Rated Voltage；Maximum Allowable Voltage (VDC): 130% of Rated Voltage；Pull-in Time (at Rated Voltage): 10ms；Release Time (at Rated Voltage): ≤5ms；Humidity: 5%~85% RH
- This relay is suitable for household appliances or DIY projects； Package Includes: 15 Mini Relays, convenient for replacement and simultaneous use in multiple projects.
| UPC | 768383220384 |
|---|---|
| ASIN | B0DH2G4HTF |
| Brand Name | YFUSET |
| Unit Count | 15 Count |
| Part Number | ZGW-34 |
| Coil Voltage | 12 volts_of_direct_current |
| Contact Type | Normally Open |
| Manufacturer | YFUSET |
| Mounting Type | PCB Mount |
| Connector Type | Plug-In |
| Current Rating | 10 A |
| Operation Mode | Automatic |
| Number of Items | 15 |
| Contact Material | Silver |
| Specification Met | CE |
| Included Components | relays |
| Contact Current Rating | 10 A |
| Minimum Switching Voltage | 250 volts_of_alternating_current |
